Pick and Place | Yamaha
The Yamaha YSM20-2 (2014 vintage) is a high-performance modular pick & place machine engineered for speed, precision, and production flexibility. Designed as an enhanced version within the YSM series, the YSM20-2 supports dual-lane operation, allowing higher throughput and optimized floor utilization. This machine is configured with dual high-speed placement heads and flying vision alignment system, enabling accurate placement of micro components up to large ICs. Its modular platform allows easy line balancing and scalability for EMS and OEM manufacturers handling medium to high-volume production. With intelligent feeder compatibility and strong tray handling support, the YSM20-2 is suitable for automotive electronics, LED lighting, industrial control boards, telecom PCBs, and mixed high-density assemblies. The 2014 unit has been tested for operational readiness and is compatible with standard left-to-right PCB flow SMT lines.
Direct inquiry to administrator
| Parameter | Description / Value |
|---|---|
| Placement Speed (Rated) | Up to 90,000 CPH |
| Practical Speed | 55,000 to 70,000 CPH |
| Placement Accuracy | ±35 microns (Cpk ≥1.0) |
| Component Range | 0201 mm to 55 × 100 mm components |
| PCB Size Range | Up to 810 × 460 mm |
| Feeder Type | Yamaha ZS / SS / Intelligent Feeders compatible |
| PCB Flow Direction | Left to Right |
| Vision System | Flying camera system |
| Head Configuration | 2 High-Speed Placement Heads |
Dual-lane production capability
High-speed dual-head platform
Flying vision alignment system
Intelligent feeder compatibility
Modular scalable design
Stable high-volume performance
Suitable for LED
automotive and industrial SMT lines
